Cleaning Main Brushes
Main brushes do not need to be cleaned after each use. However, regular cleaning is recommended to avoid
excessive build up of hair that could damage the robot.
1. Turn off the power switch and put the robot on a flat surface with
its bottom up.
2. Remove the brush retainer by pushing on the flap.
3. Take out the main brush and the rubber brush as shown in the
illustration.
4. Remove all hairs and dirt from both brushes. Plus, clean brush
chamber.
5. Wipe out dirt on the shaft and bearing of the brush.
6. Place brushes back into the slot.
7. Put the brushes retainer back and push until you
hear a clicking sound.
