Getting to know the control panel
• During navigation, arrows pointing left <
or right > identify the possibility of performing horizontal
or actions.
• The sensitive area for and actions is equivalent to all the display of the control panel and acts
on the element that has the active focus on the page.
• Being a touch screen display, it is advised to use a fingertip with a light pressure that however is more than just
skimming over it; performance increases if you press with a fingertip or even better with a nail.
• It is permissible to use a specific stylus for a touchscreen; whereas it is recommended not to use any sharp
object such as a pen, screwdriver, electric cable, etc., to avoid damaging the display.
Each action carried out on the display is associated with a different acoustic signal that is only played if the action
is permissible.
Fig. 1
1.2 Control panel main screen.
The control panel's main screen displays the list relating to the main menus:
• HVAC;
• Temperature Probe;
• Scenarios;
• Events;
• Alarm System;
• Audio;
• Power Management.
The main menu is selected by touching the name of the one you want; the selection is highlighted by the black
band and by the name that becomes white in colour.
The Alarm System, Audio and Power Management menus are displayed in the second part of the screen which is
accessed by simply touching the white cursor on the right and moving it downwards (Fig. 2-3).
Main Menu
SetupLogout
To Next Page
