vimec V65 B.R. Use And Maintenance

7602040
FIG.46
FIG.47
FIG.48
11) FITTING THE PLATFORM
a) Remove the platform cover plate by unscrewing the
screws provided.
b) Make sure that the two platform supports, held in
place by a wedge and a plastic band, are in the as-
sembly position (Fig. 46/a,b).
c) Fit the platform, holding it vertical and turning it
through 90° as shown (Fig. 47).
d) Fix the platform to the frame with the M8 flat-head
screws provided (Fig. 47/a).
e) Connect the connector j4 (Fig. 48)
32
c
a
b
d
a
