38
Vincent
Frequency response: 20 Hz - 20 kHz ±0.5 dB
Nominal Output Voltage: 2 V
Total Harmonic Distortion: < 0.1% (1 kHz, 1 W)
Input sensitivity: 500 mV
Signal to Noise Ratio:
Input Impedance:
AC power connection type:
Inputs:
Outputs:
Dimensions:
Weight:
Colour:
Tubes:
> 90 dB
47 kΩ
9a+]ZDWWVPD[
5 x RCA stereo (LINE IN), 1 x XLR-IN
2 x RCA stereo (PRE OUT), 1x XLR-OUT
1 x RCA stereo (REC OUT),
1 x Power Control
430 x 77 x 360 mm
6,2 kg
silver / black
4x 6H16
Symptom Possible Cause Countermeasure
No audio playback
on one channel
소
The source equipment is
giving signal on only one channel.
One of
the signal cables between audio sour-ce and
preamplifier inputs has not yet been plugged in
or is defective.
One or
more audio signal cables between pre- and
main amplifier are defect or one of the plug
connections is loose.
메인앰프와 스피커 연결 불량 또는 스
피커 불량
One of the speaker cables is not
correctly connected to the main amplifier or is
defective.
Check the audio source. You
can try to use itat a different amplifier for a test.
Check the
cable connections, tighten them if necessary.
Check and tighten all
cable connections.
Check and refasten the
speaker cables at the speaker terminal of the main
amplifier and at the speaker’s connectors.
Poor sound quality
.
The cable connections are not tight, the con-
nectors are dirty or a cable is defective.
The tone settings
“TREBLE” or“BASS” have not been selected
correctly.
A record player
has been connected to a line level input without
using a phono preamplifier.
Check the
cables and cable connections.
Check the settings
selected there.
Interconnect
a phono preamplifier.
한
SEARCH FOR ERRORS
.
Humming low
frequency noise is
audible, even as no audio
source is playing back
See section "Net frequency noise" in
the chapter "Tips".
See section "Net frequency noise" in the
chapter "Tips".
TECHNICAL SPECIFICATIONS
