VIPA SLIO - CC_I Comparison value; CS_I Set value

Bit Name Function
8 STS_C_UP Status set
at counter direction forward
9 STS_CMP* Status comparison is set
when the comparison condition is
met.
If comparison is parameterized
never,
the bit is never set
10 STS_END* Status is set
when end value was reached
11 STS_OFLW* Status is set at overflow
12 STS_UFLW* Status is set at underflow
13 STS_ZP* Status is set at zero run
14 STS_LTCH Status of the latch input
15 - reserved
*) The bits remain set until reset with RES_SET (bit 6 control word).
In the SLIO module there is a timer (µs ticker). With PowerON the
timer starts counting with 0. After 65535µs the timer starts with 0
again. With each change of the counter value the timer value is
stored as 16bit µs value together with the counter value in the input
area.
Addr. Name Bytes Function IX SX
+0 CC_I 4 Comparison
value
5600h 01h
+4 CS_I 4 Set value 5601h 02h
+8 CCTRL_I 2 Control word 5602h 03h
With comparison value a value may be preset that may influence the
counter output res. throw a process interrupt when compared with the
recent counter value. The behavior of the output res. the process
interrupt may be set via the parameter MODE2_I respectively INT_I.
By means of the set value there is the possibility to preset the counter
with the set value. The set value is kept by the counter by edge 0-1 of
the bit COUNTERVAL_SET in the control word.
Bit Name Function
0 CTRL_SYNC_SET activates the reset mode
1 CTRL_DO_SET enables the digital output
C_US µs ticker
Output area 10byte
CC_I Comparison value
CS_I Set value
CCTRL_I Control word
VIPA System SLIODeployment
In-/Output area
HB300 | FM | 050-1BA00 | GB | 14-36 42
