VIPA SLIO - 4.2 In-;Output area

The following behavior for the output channel may be set via the
parameterization:
n No comparison: output is not influenced
n Counter value ³ comparison value: output is set
n Counter value £ comparison value: output is set
n Counter value = comparison value: output is set
Please consider that the output may only be controlled, when the bit
STS_CTRL_DO in the counter status is set.
4.2 In-/Output area
Bei CPU, PROFIBUS und PROFINET wird der Ein- bzw. Ausgabe-
bereich im entsprechenden Adressbereich eingeblendet.
IX - Index für Zugriff über CANopen
SX - Subindex für Zugriff über EtherCAT
Addr. Name Bytes Function IX SX
+0 CV_I 4 Counter value 5400h 01h
+4 CL_I 4 Latch value 5401h 02h
+8 CSTS_I 2 Counter status 5402h 03h
+10 C_US 2 µs ticker 5403h 04h
The counter value always contains the current value of the counter.
With an edge 0-1 at the Latch input the recent counter value is stored
at Latch value.
Bit Name Function
0 STS_SYNC Reset was active
1 STS_CTRL_DO Is set
when digital output is enabled
2 STS_SW-GATE Status software gate
(set when SW gate is active)
3 STS_RST Status reset input
4 STS_STRT Status hardware gate
(set when HW gate is active)
5 STS_GATE Status internal gate
(set when internal gate active)
6 STS_DO Status digital counter output (DO)
7 STS_C_DN Status set
at counter direction backward
Counter output
Input area 12byte
CV_I Counter value
CL_I Latch value
CSTS_I Counter status
