VIPA SLIO - Isolation; Datasizes; Physical Properties

Order no. 050-1BA00
Process alarm yes, parameterizable
Diagnostic interrupt yes, parameterizable
Diagnostic functions yes, parameterizable
Diagnostics information read-out possible
Module state green LED
Module error display red LED
Channel error display none
Isolation
Between channels -
Between channels of groups to -
Between channels and backplane bus
ü
Between channels and power supply -
Max. potential difference between circuits -
Max. potential difference between inputs (Ucm) -
Max. potential difference between Mana and
Mintern (Uiso)
-
Max. potential difference between inputs and
Mana (Ucm)
-
Max. potential difference between inputs and
Mintern (Uiso)
-
Max. potential difference between Mintern and
outputs
-
Insulation tested with DC 500 V
Datasizes
Input bytes 12
Output bytes 10
Parameter bytes 25
Diagnostic bytes 20
Housing
Material PPE / PPE GF10
Mounting Profile rail 35 mm
Mechanical data
Dimensions (WxHxD) 12.9 mm x 109 mm x 76.5 mm
Weight 60 g
Environmental conditions
Operating temperature 0 °C to 60 °C
Storage temperature -25 °C to 70 °C
VIPA System SLIOHardware description
Technical data
HB300 | FM | 050-1BA00 | GB | 14-36 36
