3.3 Technical data
Order no. 050-1BA00
Type FM 050
Module ID 08C1 3800
Current consumption/power loss
Current consumption from backplane bus 75 mA
Power loss 1 W
Technical data digital inputs
Number of inputs 5
Cable length, shielded 100 m
Cable length, unshielded -
Rated load voltage DC 20.4...28.8 V
Reverse polarity protection of rated load
voltage
-
Current consumption from load voltage L+
(without load)
20 mA
Rated value DC 20.4...28.8 V
Input voltage for signal "0" DC 0...5 V
Input voltage for signal "1" DC 15...28.8 V
Input voltage hysteresis -
Frequency range -
Input resistance -
Input current for signal "1" 3 mA
Connection of Two-Wire-BEROs possible
ü
Max. permissible BERO quiescent current 0.5 mA
Input delay of "0" to "1" 0.8 µs
Input delay of "1" to "0" 0.8 µs
Number of simultaneously utilizable inputs hori-
zontal configuration
5
Number of simultaneously utilizable inputs ver-
tical configuration
5
Input characteristic curve IEC 61131-2, type 1
Initial data size 12 Byte
Technical data digital outputs
Number of outputs 1
Cable length, shielded 100 m
Cable length, unshielded 100 m
Rated load voltage DC 20.4...28.8 V
