VIPA SLIO - 4.3 Parameter data

Bit Name Function
2 SW_GATE_SET sets the software gate
3 ...
4
- reserved
5 COUNTERVAL_SET sets counter temporarily
to the value of set value
6 RES_SET resets the bits
STS_CMP, STS_END,
STS_OFLW, STS_UFLW
and STS_ZP with edge 0-1
7 - reserved
8 CTRL_SYNC_RESET deactivates the reset mode
9 CTRL_DO_RESET disables the digital output
10 SW_GATE_RESET resets the software gate
11 ...
15
- reserved
4.3 Parameter data
Via parameterization you may define among others:
n Interrupt behavior
n Input filter
n Counter operating mode res. behavior
DS - Data set for access via CPU, PROFIBUS and PROFINET
IX - Index for access via CANopen
SX - Subindex for access via EtherCAT
Name Bytes Function Default DS IX SX
DIAG_EN 1 Diagnostic interrupt* 00h 00h 3100h 01h
CH0A 1 Input frequency track A 02h 01h 3101h 02h
CH1B 1 Input frequency track B 02h 01h 3102h 03h
CH2L 1 Input frequency Latch 02h 01h 3103h 04h
CH3G 1 Input frequency Gate 02h 01h 3104h 05h
CH4R 1 Input frequency Reset 02h 01h 3105h 06h
CH5 1 reserved 00h 01h 3106h 07h
INT_I 1 Interrupt behavior* 80h 80h 3107h 08h
FCT_I 1 Counter function* 40h 80h 3108h 09h
MODE2_I 1 Counter mode 2* 00h 80h 3109h 0Ah
Parameters
VIPA System SLIO Deployment
Parameter data
HB300 | FM | 050-1BA00 | GB | 14-36 43
