Gate control via SW/HW gate, interrupting
SW gate HW gate Reaction Counter
edge 0-1 1 Continue
1 edge 0-1 Continue
Gate control via SW/HW gate, operating mode "Count once": If the
internal gate has been closed automatically it may only be opened
again under the following conditions:
SW gate HW gate Reaction I gate
1 edge 0-1 1
edge 0-1
(after edge 0-1
at HW gate)
1 1
As soon as during a count process an edge 0-1 is recognized at the
"Latch" input of the counter, the recent counter value is stored in the
latch register. You may access the latch register via the input area.
After a STOP-RUN transition latch is always 0.
The compare value is to be pre-defined by CC_I. As soon as a com-
parison condition is kept, the bit STS_DO of the counter status is set.
Please consider that the bit STS_DO may only be influenced when in
the counter status the bit STS_CTRL_DO is set. You pre-define the
behavior of the counter output via the parameterization (MODE2_I):
n output never switches
n output switches when counter value ³ comparison value
n output switches when counter value £ comparison value
n output switches at comparison value
Output never switches
The output never switches.
Output switches when counter value
³
comparison value
The output remains set as long as the counter value is higher or
equal comparison value.
Output switches when counter value
£
comparison value
The output remains set as long as the counter value is lower or equal
comparison value.
Pulse at comparison value
When the counter reaches the comparison value the output is set for
the parameterized pulse duration. If the pulse duration = 0 the output
is set until the comparison condition is no longer met. When you've
set a main counting direction the output is only set at reaching the
comparison value from the main counting direction.
Pulse duration
Gate control "Count
once"
Latch function
Comparison
VIPA System SLIODeployment
Counter additional functions
HB300 | FM | 050-1BA00 | GB | 14-36 54
