VIPA SLIO - CHOERR channel-specific; DIAG_US µs ticker

Byte Bit 7 ... 0
0 Number of channels of the module (here 01h)
Byte Bit 7 ... 0
0
n Bit 0: set at error in channel group 0
n Bit 7 ... 1: reserved
Byte Bit 7 ... 0
0 Diagnostic interrupt due to process interrupt lost at ...
n Bit 0: Hardware gate open
n Bit 1: Hardware gate closed
n Bit 2: Overflow/underflow/end value
n Bit 3: Comparison value reached
n Bit 4: Latch value stored
n Bit 7 ... 5: reserved
Byte Bit 7 ... 0
0 reserved
Byte Bit 7 ... 0
0 ... 3 Value of the µs ticker at the moment of the diagnostic
µs ticker
In the SLIO module there is a timer (µs ticker). With PowerON the
timer starts counting with 0. After 2
32
-1µs the timer starts with 0 again.
NUMCH Channels
CHERR Channel error
CH0ERR channel-spe-
cific
CH1ERR ... CH7ERR
reserved
DIAG_US µs ticker
VIPA System SLIO Deployment
Diagnostic and interrupt
HB300 | FM | 050-1BA00 | GB | 14-36 61
