USER MANUAL
4
ENGLISH
TECHNICAL DATA
Model AS430B AS510B
Machine Height 980mm
Solution tank capacity 40 litre
Recovery tank capacity 40 litre
Diameter of transport wheel 200mm
Diameter of guide wheel 76mm
Power of vacuum system motor 350w
Maximum gradient when working
2
％
(Max)
Sound pressure level at workstation
70dB(A
）
±3dB(A)
Standard batteries (2×12V) 24V 85Ah AGM (2×12V) 24V 105Ah AGM
Battery compartment size (W x L x H) 340 x 330 x 260mm(Max)
Vacuum system circuit capacity
1200 mm H
2
O
Cleaning width
430mm 510mm
Squeegee width
730mm 790mm
machine maximum length
1060mm 1100mm
Machine width without squeegee
480mm 540mm
Brush diameter
430mm 510mm
Weight with batteries and with empty tanks
112kg 128kg
Gross weight of the machine ready for use 152kg 168kg
Brush motor power
550W 560W
Brush speed
150rpm
Brush /pad-holder Maximum pressure
30kg (Max) 35kg(Max)
Packing size (Lx W x H)
1200 x 610 x 1170mm
MACHINE DESCRIPTION
MACHINE STRUCTURE
1. Safety switch button 20. Squeegee adjusting handwheel
2. Handlebar 21. Squeegee rear support frame
3. Control panel 22. Squeegee front support frame
4. Serial number plate/Technical data
/ Conformity certification
23. Cup holder
5. Control cover 24. Recovery tank cover handle
6. Cable holder (*) 25. Recovery tank cover
7. Battery charging indication light 26. Tank body
8. Reset switch 27. Water inlet cover
9. Battery connector 28. Brush deck
10. Battery cover 29. Brush / pad-holder
11. Vacuum tube for waste 30. Vacuum system motor
12. Squeegee drawing cord 31. Brush motor
13. Battery connector safety cover 32. 8” wheel
14. Squeegee lifting handle 33. Battery
15. Draining hose 34. Vacuum tube
16. Squeegee fixed knob 35. Charger (*)
17. Squeegee clip 36. Float filter
18. Squeegee blade 37. Water level tube ( to indicate amount of water
in Solution tank)
19. Squeegee support frame
(*) applicable only to machines already installed with on-board charger (optional)
