USER MANUAL
12
charger cable disconnected.
All maintenance procedures must be performed by qualified personnel, or by
authorized Service Center. This Manual describes only the most common maintenance.
For additional maintenance procedures, contact your local Service Center.
SCHEDULED MAINTENANCE TABLE
Procedure
After each use
Weekly
Every six mouths
Annually
Battery charging
Clean Squeegee
Clean Brush/Pad
Clean Tank and vacuum
grid with float, cover
gasket check
Squeegee blade check
and replacement
Recovery filter cleaning
Clean solution filter
Screw and nut
tightening check
（1）
lubricate moving parts
（1）
Brush/Pad-holder
motor carbon brush
check or replacement
（2）
Vacuum system motor
carbon brush check or
replacement
（2）
Drive motor check or
replacement
（2）
（1） And after the first 8 working hours.
（2） This maintenance procedure must be performed by an authorized Service Center.
SQUEEGEE CLEANING AND BLADE REPLACEMENT
For optimal performance, the squeegee blades must be clean, dry and undamaged. If
damaged, replace it.
1. Unscrew the knob (B2) to remove squeegee.
2. Unscrew the left and right knob to relax the front clamp, replace the front blade.
3. Disengage the retainers (B4) and remove the rear clamp, replace the rear blade.
4. Install the blades in the reverse order to removal.
5. Install the squeegee to screw the knob (B2).
