Viper Fang15B - TECHNICAL DATA; Control Panel Identification

9
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
US
ER!MANUAL!
!
C
ontrol Panel
46． Co
ntrol panel 51．Battery indicator
47． Main switch 52．Brush motor indicator
48． Brush motor switch 53．Vacuum motor indicator
49． Vacuum motor switch 54．Solution indicator
50． Solution switch
T
ECHINICAL DATA
MODEL FANG15B
Machine length / width / height 770x500x550MM
Solution tank capacity 15L
Recovery tank capacity 15L
Wheel diameter 254MM
Brush motor 24V/250W
Vacuum motor 24V/250W
Solenoid valve 24V
Maximum gradient when working 2%
Sound level 70dBA
Standard Batteries
Dry:（2×
12V）24V 33Ah
Batteries size 196 x 130 x 175mm
Power cable length N / A
Cleaning productivity
750m
2
/hour
Squeegee width 490mm
Brush diameter 380mm
Brush rpm 150rpm
Charger
Input 110-224Vac,50-60HZ；Output 24Vdc,5A
Machine net weight 60kg
Machine weight(with charger and
package)
65kg
Carton spec 780x415x590MM
