Viper Fang15B - Squeegee Installation

3
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
US
ER!MANUAL!
3. Mo
unt the brush or pad driver onto the drive wheel hub and then rotate counterclockwise until it
locks, as indicated in figure3.
4. To remove the brush/pad, rotate the brush/pad clockwise until it is released from drive hub.
WARNI
NG
Do
not turn on the machine in this position as below. In case of brush/pad come out or cause injury.
Sq
ueegee installation
1． Tu
rn off the machine. (47)
2． Pull down the squeegee lift lever (26) to put down the squeegee in the “working” position.
3． Lay down the machine in this position as shown in figure2.
4． Loosen the two knobs (55) on the squeegee and slide the squeegee into the slots on the
squeegee brackets.
5． Tighten the knobs securely. (unscrew the knobs, if to remove)
6． To replace the front/rear squeegee, (56/57) unscrew the thumb knobs. (37)
Fig
ure!3!
Fig
ure!2!
