Viper Fang15B - Page 12

11
I
tem Part No. Description Qty
1 VF89100 KIT, SOLUTION TANK 1
2 VF89018 LABEL, SOLUTION TANK 1
3 VF89200 KIT, AXLE WHEEL 1
4 VF14251 BOLT, M8X30, HEX HEAD 2
5 VF13514A WASHER, D8X1XD16.5 5
6 VF14516 NUT, NYLON INSERT, M8 4
7 VF89300 KIT, MOTOR MOUNTING PLATE 1
8 VF85698 HEX SOCKET SCREW, M8X55 2
9 VF89030 BUSHING 2
10 VF14258 HEX SOCKET SCREW, M8X40 1
11 VF14503 NUT, M8 1
12 VF89400 KIT, SKIRT ASSEMBLY 1
13 VV13664 WASHER, D4X1XD8 15
14 VF13491 PH SCREW, M4X12 16
15 VF89500 KIT, SQUEEGEE 1
16 VF89029 HOSE, CONNECT SQUEEGEE 1
17 VF85420 THUMB SCREW 2
18 VF89600 KIT, HANDLE ASSEMBLY 1
19 VF89001 HANDLE BLOCK, LEFT 1
20 VF89002 HANDLE BLOCK, RIGHT 1
21 VF89003 CIRCUIT BOX 1
22 VV60220S1 HEX SOCKET SCREW, M6X15 8
23 VV20290 WASHER LOCK, ¢6 8
24 VF13614 WASHER, ¢6 14
25 GT13027 PH SCREW, M5X45 1
26 VA13482 WASHER, D5X1XD10 6
27 VF89004 LATCH, RECOVERY TANK 1
28 VF89005 SPRING, PRESS 1
29 VF89023 KIT, CHARGER 1
30 VF89025-1 PLATE, MAIN CONTROL 1
31 VF89006 CIRCUIT COVER 1
32 VF14301 SCREW, M4X12 2
33 VF89034 HEX BOLT M6X50 6
34 VF89052 COVER, WATERPROOF 1
35 VF89037 PLUG, RUBBER 1
36 VF89035 COVER NUT, M6 6
37 VF89016 LABEL, CHARGE DISPLAY 1
38 VF89012 HANDLE GRIP, RUBBER 2
39 VF89017 LABEL, REAR HOUSING 1
40 VF89007 CABLE, SQUEEGEE LIFT 1
41 VF89008 HANDLE, SQUEEGEE LIFT 1
42 VV20509 PH SCREW, M5X10 5
43 VF89010 ROTATE AXLE, SQUEEGEE LIFT CABLE 2
44 VF89011 AXLE, SQUEEGEE LIFT CABLE 1
45 VF89009 ROTATE AXLE, SQUEEGEE LIFT CABLE 1
46 VF89056 SOLENOID VALVE, 24V 1
47 VF14514 NUT, NYLON INSERT, M5 1
48 VF89033 HOSE 1
49 VF89013 PIPE SI, D4XD8, 0.7M 1
50 VF89014 PIPE SI, D6XD10, 0.4M 1
51 VF89015 PLATE 6
VF89801 BRUSH ASSEMBLY 1
VF89804 PAD DRIVER 1
53 VF85102 SMALL CLAMP 1
54 VF89055 RUBBER PLUG, CHARGER INSERT 1
55 VF89020 BATTERY, 2-12V 35Ah 1
56 VF89036 POWER WIRE 1
57 VF89021 KIT, BATTERY CONNECT LINE 1
58 VA13473 PH SCREW, M4X16 5
59 VF89700 KIT, RECOVERY TANK 1
60 VF85141 BIG CLAMP 1
61 VA13472 PH SCREW, M4X8 2
52
COMPLETE(MACHINE(-(FANG15B
