15
I
tem Part No. Description Qty
1 VF89301 PLATE, MOTOR MOUNT 1
2 VF89302 BRUSH MOTOR ASSEMBLY 1
3 VF89303 SCREW, M6X14 4
4 VF89304 BOLT, DIRVE BELT 1
5 VF89305 O-RING, BIG 1
6 VF89306 SEALING COVER, VACUUM 1
7 VF89307 O-RING, SMALL 1
8 VF89309 KIT, VACUUM MOTOR 1
9 VF89310 BRACKET, VAC MOTOR 2
10 VF13491 PH SCREW, M4X12 3
11 VF89311 WASHER, THIN 1
12 VF89312 PLATE, SQUEEGEE ROTATE 1
13 VF89313 GUIDE WHEEL, SQUEEGEE 2
14 VA13482 WASHER ¢5 2
15 VA13475 PH SCREW, M5X25 3
16 VF14514 NUT, NYLON INSERT, M5 2
17 VF89314 KIT, BELT ADJUSTMENT 1
18 VF14223 SCREW, M6X25 1
19 VF14506 NUT, NYLON INSERT, M6 4
20 VF13614 WASHER, ¢6 3
21 VV20058 BOLT, M6X25, HEX 1
22 VF89318 SPRING 1
23 VF89319 BUSHING, SQUEEGEE ROTATE 1
24 ZD45425 BEARING, 6204 2
25 VF89320 BUSHING 1
26 VF89321 DRIVE HUB 1
27 VF89322 NUT, M20 1
28 VF89323 DRIVE BELT, PJ270 1
29 VF89324 PLATE, SQUEEGEE LIFT 1
30 VF89325 PLATE, SQUEEGEE BRACKET 1
31 VF89326 ROTATE BOLT, SQUEEGEE LIFT 2
32 VF89038 TORSION SPRING 1
33 VF89315 PLATE, BELT ADJUSTMENT 1
34 VF89316 BOLT, BEARING 1
35 VF51126A BEARING, 6201 2
36 VF89317 WASHER, D12.2XD20X1 3
37 GT13084 SCREW, M6X20 1
38 VF89308 SILENCER SPONGE 1
39 VV13633 NUT, M5 1
40 VF89337 PRESSURE ADJUSTMENT PLATE 1
BRUSH&DECK&ASSY&-&FANG&15B
