Installation
Zeus
20
Device installation layout (recommend)
RearFront
Front view camera
Emergency
switch
Main body
External GPS
Rear
view camera
Main unit can be installed on the dashboard, within the dashboard or in the fusebox.
Front cam can be installed on the dashboard or on the window
Rear cam can be installed rear side of a vehicle or outside.
GPS should be placed near the window side of dashboard and must face towards the sky.
