EN - 58
Cantorum Trio – Duo Plus Reference Manual
Appendix
Data format: F0H 31H 2nH 5CH vvH F7H
F0H : Exclusive status
31H : Viscount ID
2nH : channel number (n=0H–EH, 1-15)
5CH : tremulant depth
vvH: depth value
F7H: End of Exclusive
- Messages of Depth, Speed, Amplitude and
Shape parameters are always transmitted when
the Tremulant/Tremolo is switched on and off.
• Air Pressure
Parameter: Air Pressure
Video page: Tuning
Data format: F0H 31H 2FH 2EH vvH F7H
F0H : Exclusive status
31H : Viscount ID
2FH : system control
2EH : air pressure
vvH : air pressure value (40H–48H, 64-72)
F7H: End of Exclusive
• Ensemble
Parameter: Ensemble
Video page: Tuning
Data format: F0H 31H 2FH 32H vvH F7H
F0H : Exclusive status
31H : Viscount ID
2FH : system control
32H : ensamble
vvH : ensamble value (40H–48H, 64-72)
F7H: End of Exclusive
• Pitch
Parameter: Pitch
Video page: Tuning
Data format: F0H 31H 2FH 67H 00H 0nH 0nH 0nH F7H
F0H : Exclusive status
31H : Viscount ID
2FH : system control
67H : pitch
0nH 0nH 0nH: nibblezed data of pitch value
00H 01H 08H: A=415,30 Hz
04H 00H 00H: A=440 Hz
07H 0EH 08H: A=466,16 Hz
F7H: End of Exclusive
• Cancel
Data format: F0H 31H 2FH 6CH 00H F7H
F0H : Exclusive status
31H : Viscount ID
2FH : system control
6CH : cancel
00H : execute cancel
F7H: End of Exclusive
• Couplers (Cantorum Trio Plus)
Data format: F0H 31H 2FH 70H vvH F7H
F0H: Exclusive status
31H: Viscount ID
2FH: system control
70H: coupler
vvH: type and switch
00H=III/P on
10H=III/P off
01H=II/P on
11H=II/P off
02H=I/P on
12H=I/P off
03H=III/II on
13H=III/II off
04H=I/II on
14H=I/II off
05H=III/I on
15H=III/I off
F7H: End of Exclusive
- This message is received only.
• Couplers (Cantorum Duo Plus)
Data format: F0H 31H 2FH 70H vvH F7H
F0H: Exclusive status
31H: Viscount ID
2FH: system control
70H: coupler
vvH: type and switch
00H=II/P on
10H=II/P off
01H=I/P on
11H=I/P off
03H=II/I on
13H=II/I off
F7H: End of Exclusive
- This message is received only.
• Orchestra volume
Parameter: ORC
Video page: Levels
Data format: F0H 31H 2FH 72H vvH F7H
F0H: Exclusive status
31H: Viscount ID
2FH: system control
72H: orchestra volume
vvH: orchestra volume value (00H–7FH, 0-127)
F7H: End of Exclusive
• Orchestral Voice Change
Data format: F0H 31H 2nH 41H xxH yyH iiH ttH
v1H v2H b1H b2H o1H o2H u1H u2H kkH F7H
F0H: Exclusive status
31H: Viscount ID
2nH: channel number (n=0H–EH, 0-15)
41H: orchestral voice change
xxH: voice id – first byte
yyH: voice id – second byte
iiH: alternative voice id
ttH: timbre type
05H=single
06H=layer
07H=split
v1H:voice1/L volume
v2H:voice2/R volume
b1h: voice1/L brilliance
b2h: voice2/R brilliance
