44
Viscount Physis Organs Reference Manual
The section on which to play the melody when the Organ Solo function is active (see point 18, chap. 3):
If the notes generated with couplers are played also by orchestral stops:
in models equipped with sub- and super-octave couplers, and/or with unison off couplers, the user can select
which of these couplers will affect the orchestra stops:
- NONE: no couplers
- STD: only couplings between two manuals, or between manual and pedalboard (though not sub- and
super-octave)
- ALL: all kinds of couplers
9.7 PROGRAMMING THE [ENC] PISTON FUNCTION
(ENC. CONFIGURATION function)
This function allows to choose the expression pedal that regulates the volume of each section while the [ENC]
piston is on. To do so, select the ENC. PROGRAMMING field on the display. The following page will appear:
The organ sections can be found on the left side, while on the right the expression pedal can be selected. This
pedal will regulate the volume of the corresponding section while the [ENC] piston is on.
When the FREE option is selected, the section volume will not be affected by any pedal.
N.B.
The I/PD or II/PD optiona can be used (only for models equipped with this expression pedal) also
by assigning the MAN.I/PEDAL or MAN.II/PEDAL functions to the [CRESCENDO] pedal (see
chap. 9.6 - CRESCENDO PEDAL setting).
3 manuals models 2 manuals models
4 manuals models
