Viscount Physis - Rear Output [GEN. SUB] Equalizer

46
Viscount Physis Organs Reference Manual
-14 dB
-12 dB
-10 dB
-8 dB
-6 dB
-4 dB
-2 dB
0dB
+2 dB
+4 dB
+6 dB
+8 dB
+10 dB
+12 dB
+14 dB
Level
F
Freq
Slope = 24 dB / Oct.
9.9 REGULATING THE REAR OUTPUT [GEN. SUB] EQUALIZER (EXT. SUB
EQUALIZER function)
The rear output can connect the organ to sub-woofer systems. It is also equipped with an equalizer with low-
pass filter. Cut-off frequency and slope can be adjusted; to do so, select the EXT. SUB EQUALIZER field
under the SET-UP menu:
The parameters that can be customized are:
o SLOPE: sets the filter slope to FLAT, 12dB/oct or 24dB/oct.
o FREQ: adjusts the cutoff frequency of the filter, ranging from 80 to 300 Hz.
-14 dB
-12 dB
-10 dB
-8 dB
-6 dB
-4 dB
-2 dB
0dB
+2 dB
+4 dB
+6 dB
+8 dB
+10 dB
+12 dB
+14 dB
Level
F
Freq
-14 dB
-12 dB
-10 dB
-8 dB
-6 dB
-4 dB
-2 dB
0dB
+2 dB
+4 dB
+6 dB
+8 dB
+10 dB
+12 dB
+14 dB
Level
F
Freq
Slope = Flat Slope = 12 dB / Oct.
