6
Port Description
1. Display Mode Switch Switch between KVM display modes
2. Power LED Power LED indicator light
3. USB 2.0 Keyboard Connect a USB-A keyboard
4. USB 2.0 Mouse Connect a USB-A mouse
5. Audio Jack Connect headphones, headset or other devices with 3.5mm connector
6. USB-A 3.1 Gen 2 Ports Connect a USB-A device, supports 10Gbps transfer speeds, up to 7.5W charging
7. USB-A 3.1 Gen 2 Port Connect a USB-C device, supports 10Gbps transfer speeds, up to 7.5W charging
8. Power Switch Toggle docking station power On/Off
9. 20V DC Power Supply In Connect the included 230W 20V/11.5A Power Supply
10. USB-C Host A Upstream Port Connect to a laptop or PC, up to 10 Gbps to host, DP Alt Mode Video and USB-C
Power Delivery charging up to 100W
11. USB-C Host B Upstream Port Connect to a laptop or PC, up to 10 Gbps to host, DP Alt Mode Video and USB-C
Power Delivery charging up to 100W
12. HDMI 2.0 Port (DP Alt Mode) Display 1 - Connect a display with an HDMI port to stream video up to 4K@60Hz*
13. DP 1.2 Port (DisplayLink 1) Display 2 - Connect a display with a DP port to stream video up to 4K@60Hz
14. DP 1.2 Port (DisplayLink 2) Display 3 - Connect a display with a DP port to stream video up to 4K@60Hz
15. RJ45 Gigabit Ethernet Connect a network router or modem at 10/100/1000 Mbps
16. Kensington Security Slot Attach a standard Kensington Lock to secure docing station
DOCKING STATION PORTS (Continued)
*Note: 4K @ 60Hz max single display resolution, maximum resolution dependent on host system
specifications.
