Visonic KP-160 PG2 - 3.6 Other Functions; Appendix A: Specifications

D-303169 KP-160 PG2 User’s Guide 15
3.6 Other Functions
Output Function Actions Response
AUX Function
Enrollment: Long key press (more than 5 sec.)
until green LED lights and then release key.
Back to Factory: Long key press (more than 7
sec.) to reset the KP-160 PG2 device to factory
default settings.
Cancels current operation: Short key press
Volume control Changes the volume level upon each key press.
Volume level alternates between 1, 2, 3, 0
Mute exit beeps Mutes the exit beeps; small circle key will appear
above the key. Press button again to cancel mute.
Note: Operates only per Exit Delay duration. Upon
next Exit Delay, the exit beeps will not be muted.
APPENDIX A: SPECIFICATIONS
Frequency Band (MHz)
Europe and rest of world: 433-434, 868-869 USA: 912-919*
*Note: For UL Listed product, enable this frequency band.
Communication Protocol
PowerG
Battery type
Four 1.5V AA Alkaline batteries (GP)
Battery Life Expectancy
4 years (for typical use).
Low Battery Threshold
3.8 V
Power source (optional)
5-12VDC
Back light
Blue/white or black/white
Operating Temperature
0C to 55C (32F to 131F)
Note: For UL Listed product, the ambient temperature is
32°F to 120°F (0°C to 49°C)
Humidity
A
verage relative humidity of approx. 75% non-condensing.
For 30 days per year, relative humidity may vary from 85%
to 95% non-condensing.
Note: For UL Listed product, Relative Humidity is 93%.
Dimensions (WxLxD)
150x100x20mm (5-7/8 x 3-7/8 x 13/16 in)
Weight (including battery and
bracket)
379 g (13 oz).
Mounting
Wall-mounted or portable
Color
Black or White-Silver
APPENDIX B: COMPLIANCE WITH STANDARDS
Compliance with Standards
Europe: EN 300220-1, EN 300220-2, EN300330,
EN301489, EN60950, EN50131-1, EN50131-3, EN50131-6.
The KP-160 PG2 is compatible with the RTTE requirements
- Directive 1999/5/EC of the European Parliament and of the
Council of 9 March 1999 and EN50131-1 Grade 2 Class II.
Certified by the Dutch testing and certification bod
y
Telefication BV to the following standards:
EN 50131-3, EN 50131-6, EN 50131-5-3, EN 50130-4, and
EN 50130-5.
