Visonic PowerMaster 360

APPENDICES
D-307503 PowerMaster 360 User's Guide 63
Appendix E. Specifications
E1. Functional
Zones Number
30 wireless zones.
Installer and User Codes
 1 master installer (9999 by default)*
 1 installer (8888 by default)*
 1 master user, no. 1 (1111 by default)
 Users nos. 2 – 48
 Latchkey users 5 - 8
* Codes must not be identical
Control Facilities
Virtual keypad, wireless keyfobs and keypads
Arming Modes
AWAY, HOME, AWAY-INSTANT, HOME-INSTANT, FORCED, BYPASS.
Alarm Types
Silent, personal panic/emergency, burglary, gas (CO), and fire.
External Siren (bell) Timeout
Programmable (4 min. by default)
Supervision
Programmable time frame for inactivity alert
Special Functions
- Chime zones
- Diagnostic test and event log.
- Local and Remote Programming over Broadband and GPRS IP connections.
- Calling for help by using an emergency transmitter.
- Tracking inactivity of people.
Data Retrieval
Alarm memory, trouble, event log
Real Time Clock (RTC)
The control panel keeps and displays time and date. This feature is also used for the
log file by providing the date and time of each event
Battery Test
Once every 10 seconds
PowerG Receiver Range
160 ft. (50 m) internal, 6500 ft. (2000 m) external
Connectors
External:
 DC Power Jack
 RJ-45 Ethernet Connector
 Micro USB Connector
Internal:
 SIM Card Slot (part of GPRS Module)
 Micro SD Card Slot
 Battery Backup Connector
E2. Wireless
RF Network
PowerG – 2-way synchronized Frequency Hopping (TDMA / FHSS)
Frequency bands (MHz)
433 – 434
868 - 869
912 – 919
Hopping frequencies
8
4
50
Region
Worldwide
Europe
North America and
selected countries
Encryption
AES-128
Maximum Tx Power
10 dBm @ 433 MHz, 14 dBm @ 868 MHz
GSM (MHz)
2G Band
3G Band
850, 900, 1800, 1900
850
1
, 900
2
, 1900
1
, 2100
2
Z-Wave (MHz) (optional)
868.4, 908.4, 921.4
WiFi (optional)
2.4 GHz. Access Point is for IP camera support only
1
Covered by Module2
2
Covered by Module1
