Visonic POWERMAX+ - READING ALARM MEMORY AND TROUBLE DATA; 5.1 Reviewing Alarm;Tamper Memory

DE5467U 11
Action Resultant Display Sound

LIGHT ON

LIGHT ON 1

READY HH:MM
The lights controlled by X-10 unit No. 01 are switched on
4.3 Manual Switch-Off
You can switch appliances OFF as instructed below. This
example shows how to switch off the lights controlled by X-
10 unit No. 01.
Action Resultant Display Sound

LIGHT OFF

LIGHT OFF 1

READY HH:MM
The lights controlled by X-10 unit No. 01 are switched off
4.4 Light DIM/BRIGHT
Immediately after activating a light (see para. 4.2), you can
dim or brighten it as desired. For this purpose, enable the
DIM/BRIGHT function by pressing
or , then press
several times (as desired) the
(DIM) or
(BRIGHT)
button.
4.5 Automatic ON/OFF Control
You can select two of four options:
 By Timer ON  By timer OFF
 By sensor ON  By sensor OFF
The presently active options are shown with a dark box
(
) at the far right. To view the 2 other options click <9>.
A presently inactive option is shown without a dark box at
the far right. The dark box will appear if you click <OK>
while the option is displayed. The
☺
represents the
“Happy Tune” - successful saving of a new option.
Action Resultant Display Sound

BY TIMER ON
(if this is the default)
If not satisfied -

BY TIMER OFF
If satisfied -

BY TIMER OFF

BY TIMER OFF
☺

BY SENSOR ON
(if this is the default)
If not satisfied -

BY SENSOR OFF
If satisfied -

BY SENSOR OFF

BY SENSOR OFF
☺

READY HH:MM
5. READING ALARM MEMORY AND TROUBLE DATA
5.1 Reviewing Alarm/Tamper Memory
The PowerMax+ retains in its memory alarm and “tamper”
events that occurred during the last arming period.
Note: Alarms enter the memory only after expiry of the
“abort period” (see Appendix A). This means that if you
disarm the system immediately - before the abort period
expires - there will be no memory indication.
A. Alarm / Tamper Indications
When the memory contains at least one event and the
system is in the disarmed state, a flashing MEMORY
message will be displayed as exemplified:
READY HH:MM
(alternating)
READY MEMORY
or, if the system is not ready for arming -
NOT READY HH:MM
(alternating)
NOT READY MEMORY
B. Investigating Alarm/Tamper Data
To review memory content, click the SHOW/OK button.
EXAMPLE 1: An alarm was triggered because the garage
door - zone No. 12 - opened but then re-closed. In
addition, the bedroom motion detector - zone No. 7 - sent
a “Tamper” message because its cover had been removed.
Action Resultant Display Sound

READY HH:MM
y

Z12 ALARMED
(alternating)
y
GARAGE DOOR

Z07 TAMPER-OPEN
(alternating)
y
BEDROOM
In response to additional clicking of <SHOW/OK> button,
the display show details of other events retained in memory
(if any), or reverts to its initial state (see A above).
EXAMPLE 2
: An alarm was triggered because the garage
door - zone No. 12 - opened and was left open.
Action
Resultant Display
Sound

NOT READY HH:MM
y

Z12 ALARMED
(alternating)
y
GARAGE DOOR

Z12 OPEN
(alternating)
y
GARAGE DOOR
