20 DE5467U
The presently programmed option will be shown, with a
dark selection box (
) at the far right of the display. You
may view the other option (that does not have a dark box
at the far right) by clicking <
NEXT>. A dark box will appear
if you click <
OK> while the other option is displayed.
To set the voice option, proceed as follows:
Having entered your Master User Code
successfully (see
Para. 7.2), click the <
NEXT> button until the display reads:
SET VOICE OPTION
From here, proceed as follows:
Action Resultant Display Sound
enable prompts
(if this is the current option)
If not satisfied -
disable prompts
If satisfied -
disable prompts
SET VOICE OPTION
☺
You may now select any other item on the USER
SETTINGS menu or quit programming by clicking
<
AWAY>. When <OK> TO EXIT is displayed - click <OK>.
Note: When using the Model MCT-234 keyfob with the
PowerMax+, the voice prompts must be enabled.
7.11 Automatic Arming Option
You can determine that the system will be automatically
armed at any desired time.
Having entered master user code successfully, click NEXT
until AUTO ARM OPTION is displayed.
From here, proceed as follows:
Action Resultant Display Sound
enable autoarm
(If this is the current
If not satisfied
disable autoarm
disable autoarm
AUTO ARM OPTION
☺
You may now select any other item on USERS SETTINGS
menu or quit programming process by clicking <NEXT>.
When "<OK> TO EXIT" is displayed, click OK.
7.12 Setting Arming Time
Having entered your Master User Code successfully (see
Para. 7.2), click NEXT button (repeatedly, if necessary)
until the display will read:
AUTO ARM TIME
From here, proceed as follows:
Action Resultant Display Sound
arm time __:__A
[time digits]
(e.g. 12:55 A)
arm time 12:55A
arm time 12:55A
AUTO ARM TIME
☺
Notes:
1. For 12h/24h time format selection, refer to par. 7.14.
2. Press "
" to enter A (AM), or press "#" to enter P (PM).
7.13 Enabling the Squawk Option
You can determine that the system will activate (or not
activate) high/mid/low siren sound, for a short time, upon
arming (1 beep) and disarming (2 beeps), by keyfob only.
Having entered your Master User Code
successfully (see
Para. 7.2), click the NEXT button (repeatedly, if necessary)
until the display will read:
SQUAWK OPTION
From here, proceed as follows:
Action Resultant Display Sound
squawk disable
(If this is the current option)
If not satisfied
squawk low volume
If not satisfied
Squawk mid volume
If not satisfied
Squawk hi volume
If satisfied
Squawk hi volume
☺
For wired siren, refer to "low", "mid" and "hi" options as
"squawk enable".
You
may now select any other item on the USERS SETTINGS
menu or quit the programming process by clicking <NEXT>.
When "<OK> TO EXIT" is displayed, click OK.
7.14 Setting Time and Time Format
Having entered your Master User Code successfully (see
Para. 7.2), click <
NEXT> until the display reads:
SET TIME&FORMAT
A. If 12h format is desired, continue as follows:
Action Resultant Display Sound
US FORMAT - 12H
TIME __:__A
[time digits]
(e.g. 12:55 A)
TIME 12:55 A
TIME HH:MM A
☺
Note: To enter “A” - press [
] or to enter “P” - press [#].
B. If 24h format is desired, continue as follows:
Action Resultant Display Sound
US FORMAT - 12H
EU FORMAT - 24H
TIME __:__
[time digits]
(e.g. 19:55)
TIME 19:55
TIME 19:55
TIME HH:MM
☺
You may now select any other item on the USER
SETTINGS menu or quit programming by clicking
<
AWAY>. When <OK> TO EXIT is displayed - click <OK>.
