Page 13

Section 4.4 PTO LINKED WITH RPM CONTROL

When PTO Control is linked with RPM Control (PTO/RPM LINKED), the PTO output is activated and engine speed

is elevated in conjunction with each other. When the RPM Control is commanded off, the PTO output will also turn

off. Conversely, when the PTO output is commanded off, the RPM Control is also turned off and the engine

returns to normal idle speed. This feature requires programming.

With PTO/RPM LINKED, the operator can disable both the PTO and the elevated RPM from a remote location on

the vehicle. This requires that a remote switch is installed, which is described in Section 6.

Step 1 Program the module for PTO Linked with RPM CONTROL.

1. Go to main programming mode, press and hold [RPM CONTROL], [CHARGE PROTECT] & [FORD]

keys

2. Menu 1 should be set to "BASE" mode.*

3. Go to Menu 2 by pressing the [FORD] key. See "RPM" and "PTO" on the right hand side.

4. Change the mode from "no" to "YES" by pressing any [ARROW] key.

5. Press [Ford] key. Menu 3 shows the programmed PTO Lower Limit.

6. Press [Ford] key. Menu 4 shows the programmed PTO Upper Limit.

7. Menu 5 should be set to "BASE" mode. Press [Ford] key to exit.

* NOTE: Automatic RPM Control is not available with PTO/RPM LINKED.

Step 2 Initiate PTO Linked with RPM CONTROL mode.

• Press [RPM CONTROL] key on module.

» RPM Control Light will turn on

» RPM value stored in Memory #1 is displayed

If desired, select another RPM preset with the [ARROW] keys

» RPM value stored in the Memory selected is displayed

Step 3 Activate the RPM Control mode. PTO output will also activate.

• Press [FORD] key

to activate RPM control mode

» RPM Control Light will flash

» PTO Control Light will turn on.

» Engine speed will increase to the desired RPM

» Current engine speed is displayed

» PTO output turns on and activates the auxiliary load (PTO).

Exiting PTO/RPM LINKED mode

ANY ONE of the following will exit RPM and PTO Control Linked mode and return the engine to idle.

• Press [FORD] key

• Press [RPM CONTROL] key

• • Press [PTO CONTROL] key

• Press [POWER] key

• Press brake or clutch pedal, take vehicle out of park, or release parking brake

Or installed Remote Ford switch

VISTEON AUXILIARY IDLE User Manual
