Page 22
Section 8 FUNCTIONAL SUMMARY
VEHICLE REQUIREMENTS
Enablers required to activate high-idle modes - Parking brake engaged
- Clutch engaged (foot off) or vehicle in PARK
- Service brake off
- Foot off accelerator
- Brake lights connected and functional
Disablers allowing multiple ways of returning to idle - Press brake or clutch pedal
- Release parking brake
- Take vehicle out of PARK
- Deselect APCM function
- Turn off power to APCM
CHARGE PROTECTION MODE
Adaptive "Charge Protection" - System voltage displayed on LCD screen
- Remote activation - Use momentary contact switch
- Programmable automatic activation - Automatic transmission is required
Minimum RPM for Charge Protection - 1100 RPM (1998 MY Econoline)
- 1200 RPM (1999 MY F-Series)
- 1300 RPM (All previous Model Years for E/F-
Series)
Maximum charge rate - 2500 RPM
RPM CONTROL MODE
Selectable high idle operation with closed-loop - System RPM displayed on LCD screen
engine speed control
Programmable RPM memories - 4 presets
Minimum programmable RPM - 1200 RPM
Maximum programmable RPM - 2500 RPM
Manual RPM Control - Slow and fast up and down arrow keys
Remote RPM Control - On-off to RPM Preset #1
Custom Remote RPM Control - Adjustable from 1200 to 2500 RPM
PTO CONTROL MODE
PTO Linked operation with RPM Control - Activate PTO output and high-idle concurrently
Programmable PTO Overspeed Protection - Disabling upper limit (full RPM range)
Programmable Clutch Engagement Speed Protection - Enabling lower limit (full RPM range)
Section 9 SPECIFICATIONS
