25
Typical Electrical Safety Test Connection Diagram
E
LN
DEVICE UNDER TEST
TO V LO
TERMINAL
TO CHASSIS
SENSE TERMINAL
TO V HI
TERMINAL
The Vitrek 944i Dielectric Analyzer has been designed to provide maximum user safety, reliability, and test throughput. To
achieve this, the 944i is equipped with built-in self test capability, and a variety of user configurable test options. This section of
the manual addresses the use of the system test and configuration functions.
