Vitus Audio Reference Series - Replacing a Blown Fuse

4. OPERATION AND SERVICE
1.
The fuse carrier is placed on the back of the external
power supply under the power connector.
2.
Loosen the fuse carrier using a at object like a at screwdriver.
3.
Pull the fuse carrier out.
4.
Pull the fuse carrier out.
5.
There is a spare fuse available in the fuse carrier.
6.
Take the blown fuse out of the fuse carrier
and throw it away.
REMOVE THE POWER CABLE
24 | RD-101 Owner’s manual
Blown fuse
Spare fuse
4. OPERATION AND SERVICE
8. 9.
Push the fuse carrier into the back.
10.
The fuse carrier is in place when you hear “CLICK”.
7.
Push the spare fuse out using a pointy object.
7.
Place the spare fuse in the fuse carrier and click the fuse
in place.
Replacing a blown fuse Replacing a blown fuse
RD-101 Owner’s manual | 25
