Page 41 of 81
5 Data Logging
5.3.5 Splash Screen
On this page an image can be loaded which can be used as a splash screen by the locator when it is switched on. The locator
has an LCD screen with a resolution of 480 by 272 pixels. The image loaded into MyLocator3 will be scaled to t the width of
the screen. If the scaled image height is less than the LCD height, then the image is centered vertically and white bars are used
as padding. If the scaled image height is greater than the LCD height, then the image can be re-positioned vertically by clicking
and dragging the left mouse button anywhere on the image.
To insert your own start up screen rst click on the “Open” button. Then browse your les to select the picture required as the
startup screen. The application is compatible with le formats .jpg/.bmp/.png, and .gif.
The startup screen will be displayed in the application.
The Download button can be used to set the splash screen immediately or the image can be sent to the locator along with the
rest of the conguration by pressing the Write Conguration button.
To remove a startup screen and revert to the default Vivax-Metrotech screen click on the “Clear” button and download the
cleared screen.
