5 Data Logging
5. Data Logging
The vLoc3-Pro has an internal memory that can be used to store locator data. Available storage size is four Gigabyte which
relates to many thousands of records.
The records are user initiated. These are records stored by the user whenever the “+” button is pressed when in the “Information” screen.
Data can be stored relating to a standard locate or relating to any of the receiver accessories. (apart from the Remote antenna
accessory).
In addition to this, every time a self-test routine is run the results are also recorded in the equipment. This is not a user initiated
record; it is done automatically after every self-test.
Warnings/Alarms are also automatically recorded.
To store a record rst locate a point of interest. Hold the vLoc stationary over the target and press the “i” pushbutton. When in
the depth and current screen, press the “+” pushbutton to save the data. The “Log” number indicates the number of records
stored. To exit the screen without logging the data, press the “-” button.
Log 1
0.87m 261mA
50°42′59.90570′′N
3°26′35.54358′′W
27.50m
0
SD
If the GPS function is enabled the GPS coordinates will also be displayed and attached to any saved le. For more information
on Data logging and GPS see section 5.2.5.4.
When the save button is pressed the Log number will increment and the arrow below the check sign will turn green indicating
that the data has been stored successfully.
Log 2
0.54m 163mA
50°42′59.90570′′N
3°26′35.54358′′W
27.50m
0
SD
The screen will then automatically revert to the locate or accessory screen.
The data log can also be deleted from the Info screen. From the Info screen press and hold the “-” key. The message below will
be shown.
Delete all logs?
