Page 71 of 81
8 Using the Accessories
A-frame Datalogging
Data logging is possible when the A-fame is connected. Make sure the A-frame is located in the desired position with the pins
firmly inserted in the ground.
8KFF
Log
6
To record data press the “+” button. The soft key on the display will momentarily go green indicating that the data is stored, and
the Log number will increment.
The data log can also be deleted from the Info screen. From the A-frame screen press and hold the “-” key. The message below
will be shown.
Delete all logs?
Press the “+” key to confirm. The locator will ask again “Are you sure?”. Press the “-” key to delete or the “+” key to cancel the
deletion and return to the locate/accessory screen.
Are you sure?
Deleting logs....
8.3 Using the vLoc3-Pro Remote Antenna
The remote stethoscope antenna can be used to help trace a particular cable on a cable tray or where cables are bunched
together.
Methods:
1. Connect a signal to the cable to be identied. The remote stethoscope functions has an operational frequency range of
512Hz up to 200 kHz, but low frequencies should be a preference in this application as they are less likely to leak or bleed
over to other cables.
