3
ASSEMBLY STEPS
Plug Control Unit (F) and AC Adapter (G) into Li Column (A). Plug Power Cable (J) into AC Adapter
(G) and then connect to an outlet.
Perform the PAIRING THE REMOTE steps on page 10 to pair RF Remote (H). Once RF Remote (H)
is paired, press the down arrow and extend Li Column (A) until the last hole set has passed Wall
Mounting Plate (A1) as shown. Ensure there are no obstructions while extending Li Column (A).
STEP 1
STEP 2
A
F
G
J
A1
A
H
To Next Page
