4
STEP 3
STEP 4
Install Extension Brackets (D) to Li Column (A) using M6x6mm Screws (S-C) and 4mm Allen Wrench
(T-B). The location will be dependent on the TV size and VESA hole location.
S-CS-C
T-B
D
A
Install Cover Mount (E) onto Extension Brackets (D) using M6x10mm Screws (S-D) and 4mm Allen
Wrench (T-B).
T-B
E
D
S-D
