VIVOTEK
158 - User's Manual
100 is percentage mode.
s<0~(m-1)>_mjpeg_qvalue 2~97 49 1/4 Manual video quality level
input.
(s<0~(m-1)>_mjpeg_qu
ant = 99)
s<0~(m-1)>_mjpeg_qperce
nt
1~100 50 1/4 Manual video quality level
input.
(s<0~(m-1)>_mjpeg_qu
ant = 100)
s<0~(m-1)>_mjpeg_bitrate 4000~400000
00
FD8365:
s0:14000000
s1: 512000
FD8355:
s0:6000000
s1:512000
1/4 Set bit rate in bps when
choosing cbr in
“ratecontrolmode”.
s<0~(m-1)>_mjpeg_maxvb
rbitrate
1000~400000
00
40000000 1/4 Set bit rate in bps when
choosing vbr in
“ratecontrolmode”.
s<0~(m-1)>_mjpeg_maxfra
me
1,2,3,5,8,10,1
2,15,20,25,30
s0:10
s1:15
1/4 Set maximum frame rate
in fps (for JPEG).
3M : 1~30fps
2M : 1~60fps
(for NTSC or 60Hz CMOS)
s<0~(m-1)>_mjpeg_priority
policy
framerate,imag
equality
s0:framerate
s1:imagequality
1/4 Set prioritypolicy
wdr_mode 0~1 1 1/4 WDR enhanced.
0: off
1: on
wdr_strength 0~2 1 1/4 WDR enhanced.
0: low
1: medium
2: high
