VIVOTEK
User's Manual - 53
Please follow the steps below to setup a prole:
1. Check Enable this prole.
2. Select the applied mode: Day mode, Night mode,
or Schedule mode. Please manually enter a range
of time if you choose the Schedule mode.
3. Congure Exposure control settings in the folowing
columns. Please refer to previous dicussions for
detailed information.
4. Click Save to enable the setting and click Close to
exit the page.
You can click Restore to recall the original settings without incorporating the changes. When
completed with the settings on this page, click Save to enable the settings.
■ Maximum Exposure Time: The congurable max. exposure time is tunable according to lighting
conditions with values ranging from 1/8,000 to 1/5 of a second.
■ Maximum Gain Control: Tune the slider bar to set the Gain Control to the best image quality.
Higher gain control value will generate a certain amount of noises.
If you want to congure another sensor setting for day/night/schedule mode, please click Prole to
open the Prole of exposure settings page as shown below.
Activated period:
Select the mode this prole to apply to the Schedule mode. Please manually enter
a range of time if you choose Schedule mode. Then check Save to take effect.
