VIVOTEK - A Leading Provider of Multimedia Communication Solutions
User's Manual - 113
axisx -104 ~ 104 1/7 Axis X coordinate, used internally.
axisy -15 ~ 28 1/7 Axis Y coordinate, used internally.
preset_i<0~(npreset-
1)>_name
string[40] 1/4 Name of the preset location.
uart 0 ~ (m-1), m is
UART count
1/4 Select corresponding uart
(capability.nuart>0).
cameraid 0~255 1/4 Camera ID controlling external PTZ camera.
isptz 0 ~ 2 1/7 0: disable PTZ commands.
1: enable PTZ commands with PTZ driver.
2: enable PTZ commands with UART tunnel.
disablemdonptz <boolean> 1/4 Disable motion detection on PTZ operation.
pantilt_port <integer> 1/4 Pan and tilt channel.
pantilt_camid 0 ~ 255 1/4 ID of camera on pan/tilt channel.
zoom_port <integer> 1/4 Zoom channel.
zoom_camid 0 ~ 255 1/4 ID of camera on zoom channel.
patrolseq string[64] 1/4 (For external device)
The indexes of patrol points, separated by “,”
patroldwelling string[128] 1/4 (For external device)
The dwelling time of each patrol point, separated
by “,”
Group: uart (capability.nuart>0) (product dependent)
NAME VALUE SECURITY
(get/set)
DESCRIPTION
ptzdrivers_i<0~19, 127>_name string[40] 1/4 Name of the PTZ driver.
ptzdrivers_i<0~19, 127>_location string[128] 1/4 Full path of the PTZ driver.
enablehttptunnel <boolean> 4/4 Enable HTTP tunnel channel to control
U A RT.
Group: uart_i<0~(n-1)> n is uart port count (capability.nuart>0)
NAME VALUE SECURITY
(get/set)
DESCRIPTION
baudrate 110,300,600,120
0,2400,3600,480
0,7200,9600,192
00,38400,57600,
115200
4/4 Set baud rate of COM port.
databit 5,6,7,8 4/4 Data bits in a character frame.
paritybit none, 4/4 For error checking.
