114 - User's Manual
odd,
even
stopbit 1,2 4/4 1
2-1.5 , data bit is 5
2-2
uartmode rs485,
rs232
4/4 RS485 or RS232.
customdrvcmd_i<0~9> string[128] 1/4 PTZ command for custom camera.
speedlink_i<0~4>_name string[40] 1/4 Additional PTZ command name.
speedlink_i<0~4>_cmd string[128] 1/4 Additional PTZ command list.
ptzdriver 0~19,
127 (custom),
128 (no driver)
4/4 The PTZ driver is used by this COM port.
Group: layout (product dependent) (FD7132, FD7151)
NAME VALUE SECURITY
(get/set)
DESCRIPTION
logo_default <boolean> 1/6 0 => Custom logo
1 => Default logo
logo_link string[40] 1/6 Hyperlink of the logo
logo_powerbyvvtk_hidden <boolean> 1/6 0 => display the power by vivotek logo
1 => hide the power by vivotek logo
theme_option 1~4 1/6 1~3: One of the default themes.
4: Custom definition.
theme_color_font string[7] 1/6 Font color
theme_color_configfont string[7] 1/6 Font color of configuration area.
theme_color_titlefont string[7] 1/6 Font color of video title.
theme_color_controlbackground string[7] 1/6 Background color of control area.
theme_color_configbackground string[7] 1/6 Background color of configuration area.
theme_color_videobackground string[7] 1/6 Background color of video area.
theme_color_case string[7] 1/6 Frame color
Group: privacymask_c<0~(n-1)> for n channel product
NAME VALUE SECURITY
(get/set)
DESCRIPTION
enable <boolean> 4/4 Enable privacy mask.
win_i<0~4>_enable <boolean> 4/4 Enable privacy mask window.
win_i<0~4>_name string[14] 4/4 Name of the privacy mask window.
