42 - User's Manual
Turn Off Relay: Turn off Relay (digital output) on linked device. This function will only be enabled on
the devices with DO function.
3. Actions of the network video recorder
Turn On Relay: Turn on Relay (digital output do0) on the network video recorder.
Turn Off Relay: Turn off Relay (digital output do0) on the network video recorder.
NOTE
► You can modify the Name of digital outputs on the network video recorder. Please refer to Digital
Onput on page 46 for detailed information.
► E-mail & FTP notication
1. E-mail format:
Event Type Camera disconnected Motion on Motion off Alarm on Alarm off
Title
Event notification from
Device Y: Camera
disconnected
Event notification
from Device Y:
motion_on
Event notification
from Device Y:
motion_off
Event
notification
from Device Y:
alarm_on
Event
notification
from Device
Y: alarm_off
Content Device Y is disconnected
Device Y motion
# X on
Device Y motion
# X off
Device Y DI
Device Y-DI-X
on
Device Y DI
Device Y-DI-X
on
With Snapshot
(jpg.)
No Yes Yes Yes Yes
2. FTP format
Event
Type
Camera disconnected Motion on Motion off
Snapshot
No snapshot
motion on_Z_MAC address_date&time_
random number.jpg
mottion off_Z_MAC address_
date&time_random number.jpg
Event
Type
Alarm on Alarm off
Snapshot
alarm on_Z_MAC address_date&time_random
alarm off_Z_MAC address_date&time_random
■ “Y” refers to the Device Name. For example, IP8162. (Y=8162)
■ “X” refers to the motion window number of the device in Motion on and Motion off notication, while
it refers to digital input number in Alarm on and Alarm off notication.
For example,
Camera IP8162 mortion #1 on (X=1)
Device IP8151 DI IP8151-DI-2 on (X=2)
■ “Z” refers to the motion window number of the device. Noted that Z number 0,1,2 indicates the motion
window 1,2,3.
For example, motion_on_0_2d18332af00_20110214065122_371.jpg (Z=0, Z= motion window 1)
■ Date should be in YYYYMMDD_HHMMSS format.
For example: 20080509_122342_Motionon.jpg
► Only the event of the linked cameras will send snapshot notication.
