VIVOTEK
User's Manual - 105
axisy -786 ~ 1572 1/7 Axis Y coordinate, used internally.
axisz 4096 ~ 8859 1/7 Axis Z coordinate, used internally.
returnhome 0,1 1/4 Enable/disable auto return home while idle
returnhomeinterval 1 ~ 999 1/4 Wait interval return home
defaulthome 0,1 1/4 This field tells system to use default home position or not.
osdzoom 0,1 1/4 Enable zoom times display
digitalzoom 0,1 1/4 Enable digital zoom
preset_i<0~19>_name string[40] 1/4 Name of the preset location.
preset_i<0~19>_pan -6790 ~ 6790 1/4 The axis x coordinate of each preset location
preset_i<0~19>_tilt -786 ~ 1572 1/4 The axis y coordinate of each preset location
preset_i<0~19>_zoom 4096 ~ 8859 1/4 The axis z coordinate of each preset location
patrol_i<0~39>_name string[40] 1/4 The name of patrol location
patrol_i<0~39>_
dwelling
0 ~ 999 1/4 The dwelling time of each patrol location
Group: layout
NAME VALUE SECURITY
(get/set)
DESCRIPTION
logo_default <boolean> 1/6 0 => Custom logo
1 => Default logo
logo_link string[40] 1/6 Hyperlink of the logo
logo_powerbyvvtk_hidden <boolean> 1/6 Hide Powered by VIVOTEK
theme_option 1~4 1/6 1~3: One of the default themes.
4: Custom definition.
theme_color_font string[7] 1/6 Font color
theme_color_configfont string[7] 1/6 Font color of configuration area.
theme_color_titlefont string[7] 1/6 Font color of video title.
theme_color_controlbackground string[7] 1/6 Background color of control area.
theme_color_configbackground string[7] 1/6 Background color of configuration area.
theme_color_videobackground string[7] 1/6 Background color of video area.
theme_color_case string[7] 1/6 Frame color
Group: capability
NAME VALUE SECURITY
(get/set)
DESCRIPTION
api_httpversion 0100a 0/7 The HTTP API version.
bootuptime <positive integer> 0/7 Server bootup time.
nir 0, 0/7 Number of IR interfaces.
