VIVOTEK
User's Manual - 95
customlanguage_count <integer> 0/7 Number of custom languages which have been
uploaded to the server.
customlanguage_i<0~(ma
xcount-1)>
string 0/7 Custom language name.
Group: status
NAME VALUE SECURITY
(get/set)
DESCRIPTION
videomode_c0 ntsc,
pal
4/7 The actual modulation type
(videoin.type=0).
di_i<0~(ndi-1)> <boolean> 1/7 0 => Inactive, normal
1 => Active, triggered
do_i<0~(ndo-1)> <boolean> 1/7 0 => Inactive, normal
1 => Active, triggered
onlinenum_rtsp integer 6/7 Current number of RTSP connections.
onlinenum_httppush integer 6/7 Current number of HTTP push server connections.
eth_i0 <string> 1/99 Get network information from mii-tool.
Group: di_i<0~(ndi-1)>
NAME VALUE SECURITY
(get/set)
DESCRIPTION
normalstate high,
low
1/1 Indicates open circuit or closed circuit (inactive
status)
Group: do_i<0~(ndo-1)>
NAME VALUE SECURITY
(get/set)
DESCRIPTION
normalstate open,
grounded
1/1 Indicate open circuit or closed circuit (inactive
status)
Group: security
NAME VALUE SECURITY
(get/set)
DESCRIPTION
privilege_do view, operator, admin 6/6 Indicate which privileges and above can control
digital output
privilege_camctrl view, operator, admin 6/6 Indicate which privileges and above can control PTZ
user_i0_name root 6/7 User name of root
user_i<1~20>_name string[64] 6/7 User name
user_i0_pass password[64] 6/6 Root password
