Vixel 9000 Series Installation & Configuration Guide CHAPTER 6 Zoning
45
zone menu
To view the zone menu, type the following command from the Root Menu:
config zone wwn zone
Object names (for new or existing Zone Sets, Zones, or Members) must be enclosed
in quotes when specified.
While the command examples shown within the menu specify one or more object
names (an object being a Zone Set, Zone, or Member), you may enter just the
command. If the required object names are not specified when the command is
entered, then you are prompted either for the desired name or for selection of one or
more objects from a list of those available.
>config zone wwn zone
Menu
1) back - Go back
2) show - Show zones (Example: >show)
3) zadd - Add zone (Example: >zadd "zone 1" "zone set 1")
4) zdel - Delete zone (Example: >zdel "zone 1")
5) madd - Add member (Example: >madd "23 45 AB CD 98 76 EF CD" "zone 1")
6) mdel - Delete member (Example: >mdel "23 45 AB CD 98 76 EF CD")
7) define - Define members within zones (Example: >define "zone 1")
(config/zone/wwn/zone)>
Command Description
back
Displays the menu that is one level upwards.
show
Displays all configured Zones. When a Zone is selected, con-
stituent Members are shown.
zadd
Adds (creates) one or more empty Zones.
zdel
Deletes (removes) all occurrences of the specified Zone. A
deleted Zone is no longer available for configuration.
madd
Adds specified Member to the specified Zone. If no Member is
specified, then all World Wide N_Port_Names within the exist-
ing fabric are displayed.
mdel
Deletes all occurrences of the specified Member. A deleted
Member is no longer available for configuration.
define
Defines (configures) Members within the specified Zone. Each
previously added Member is displayed with a Y/N prompt.
The initially displayed value within the prompt reflects the cur-
rent status of the Member in relation to the specified Zone.
