Vixel 9000 Series Installation & Configuration Guide APPENDIX B Default Firmware Settings
54
Port Configuration
Note: The PRLI, FAN, and
RSCN configuration
settings apply to Fabric
Mode and Fabric (Public/
Private) Mode only; for
more information, see
“Options for Fabric Mode
and Fabric (Public/Private)
Mode” on page 25.
>show ports config
Port Configuration Table
Port Name Type Module PRLI FAN Stream BB Credit MRBS RSCN
1 Port 1 6 9 1 1 8 16 16 1
2 Port 2 6 9 1 1 8 16 16 1
3 Port 3 6 9 1 1 8 16 16 1
4 Port 4 6 9 1 1 8 16 16 1
5 Port 5 6 9 1 1 8 16 16 1
6 Port 6 6 9 1 1 8 16 16 1
7 Port 7 6 9 1 1 8 16 16 1
8 Port 8 6 9 1 1 8 16 16 1
Current Port Number: 1
Legend for enumerated columns:
# Type Module PRLI FAN RSCN
1 fPort unknown true true normal
2 flPort dualFrequencyShortwave false false TxOnly
3 ePort dualFrequencyLongwave RxOnly
4 stealthLoop fcLaserShortwave noRSCN
5 autoDetect serialModDef
6 gPort fcLaserLongwave
7 copperIntraCabinet
8 copperInterCabinet
9 noModule
Note: The values in the
EDTOV, RATOV, ALTOV,
and LPTO settings
represent milliseconds.
>show ports advanced
Port Configuration Table
Port RBS TBS EDTOV RATOV ALTOV LPTO RXTHRSH TXTHRSH SPEED
1 2112 16 2000 10000 15 100 3 4 3
2 2112 16 2000 10000 15 100 3 4 3
3 2112 16 2000 10000 15 100 3 4 3
4 2112 16 2000 10000 15 100 3 4 3
5 2112 16 2000 10000 15 100 3 4 3
6 2112 16 2000 10000 15 100 3 4 3
7 2112 16 2000 10000 15 100 3 4 3
8 2112 16 2000 10000 15 100 3 4 3
Current Port Number: 1
Legend for enumerated columns:
# SPEED
1 speedDetect
2 oneGig
3 twoGig
Event Log & Fault LED
>config event show
Fault LED Severity : critical
Event Log Severity : notify
