Fusebox (W)

Fuel Filter (L)

Starter (V1)

Oil lter (L1)

Cooler (B)

Alternator (V)

Injector (S)

Electronic control unit (N)

Rail (S1)

Fuel Filter (L)

Starter (V1)

Cooler (C)

Oil lter (L1)

Oil sump (M)

Intercooler (E)

Coolant ller plug (U1)

Coolant expansion

tank (U)

Fresh water pump (P)

High pressure

injection pump

(R)

Alternator belt (T)

Alternator belt tensioner (T1)

Seawater pump (Q)

Seawater pump inlet (Y)
