MR 700
41
Ed. 3 - 2012_11
English
tensioner (A)
METHOD FOR TIGHTENING OR LOOSENING THE BELT
Follow the procedure below.
1 -Turn off the engine and remove the
ignition key.
2 -Let the engine cool down adequately to
avoid being burnt.
3 -Loosen the belt by moving the ten-
sioner (A) until the holes (B) match and
block it with pin (C).
4 -Tension the belt by moving the tensio-
ner (A), remove the pin (C) and release
it..
Warning - Caution
To tighten the belt, it must be cor-
rectly positioned in the housings on
each of the pulleys (see “Belt repla-
cement”).
hole (B)
pin (C)
