R750EU5 - IE3 - TE4 - IE4 - ISE4
English 51 Ed.8 / 10-2012
GB
ENGINE OIL CHANGE
Filler cap (M)
Drain
plug (Q)
Follow the procedure below.
Start the engine and bring it to the
operating temperature (70÷80 °C)
Turn off the engine and remove the
ignition key.
Let the engine cool down adequately
to avoid being burnt.
Prepare a container of appropriate
capacity. (As for the oil quantity, see
“Technical data”.)
Unscrew the load plug (M).
Unscrew the exhaust plug (Q) and let
all the oil ow into the container.
Replace the gasket and screw plug
(Q) back into place.
•
•
•
•
•
•
•
Lock the plug to a torque of 55 Nm.
Pour the new oil until it reaches the
correct level on the dipstick. (See
“Engine oil level control”)
Screw again the load plug (M).
Start the engine and bring it to the
operating temperature (70÷80 °C).
Check for any oil leaks.
Turn off the engine and check the oil
level. (See “Engine oil level control”)
•
•
•
•
