R750EU5 - IE3 - TE4 - IE4 - ISE4
English 54 Ed.8 / 10-2012
GB
OIL FILTER CARTRIDGE REPLACEMENT
Gasket (V)
Oil Filter (U)
Follow the procedure below.
1- Turn off the engine and remove the
ignition key.
2- Let the engine cool down adequately to
avoid being burnt.
3- Prepare a container to collect any leak.
4-Unscrew lter (U) and replace it.
5-Check the conditions of gasket (V) and,
if necessary, replace it.
6- Lubricate the seal of the new cartridge
before assembling it.
7- Install the oil lter.
Lock the screw to a torque of 25 Nm.
8- Turn the engine on and keep it running
at idle speed for a few minutes to bring it
up to working temperature (70÷80°C).
9- Turn off the engine and remove the
ignition key.
10-Wait a few minutes so that all the oil
will ow into the sump.
11-Check that the oil in the tank is at the
correct level, and top up if necessary.
(See “Engine oil level control”)
12-Check for any oil leaks
If any oil leaks are found, stop the
engine immediately and contact an
authorised service centre.
Do not throw away any polluting
material in the environment. Carry out
their disposal in compliance with the
relevant legislation in force.
