Installation and Operating Manual / Version 10 / 3626-011500
en
/ Protection class 0: public / 2017-12-15
27
BTS, non-contacting thermal switch unit
Installation
Terminal assignment: Evaluator
Terminal No.
Description
1
GND for trigger input
2
Trigger input for start-up bypass, +24 V DC
3
Power supply for trigger input.
When triggering by switching on the supply voltage, provide a bridge between
terminals 3 and 2 (as delivered condition!).
4
Supply voltage, +24 V DC
5
Supply voltage, GND
6
Do not connect!
7
Do not connect!
8
NAMUR input, L-
9
NAMUR input, L+
10
Output relay, make contact, NO
11
Output relay, break contact, NC
12
Output relay, root, COM
13
Do not connect!
14
Do not connect!
15
Do not connect!
16
Supply voltage, 230 V AC, L1
17
Supply voltage, 115 V AC, L1
18
Supply voltage, N
Table 7
