Voith BTS User Manual

BTS, non
-contacting thermal switch unit
Spare Parts Information
Installation and Operating Manual / Version 10 / 3626-011500 en / Protection Class
0: public / 2017-12-15
40
13 Spare Parts Information
NOTICE
Unauthorized changes or retrofits are not allowed to be performed on the
coupling!
Do not retrofit accessories or equipment originating from other
manufacturers!
Any changes or conversions performed without the prior written consent of Voith
Turbo will result in the loss of any warranty! Any claims will forfeit
!
•
Professional maintenance or repair can only be guaranteed by the
manufacturer!
13.1 Switching elements
BTS switching elements Sealing ring
Use for turbo
coupling size
Dimension
of thread
Nominal
response
temperature
Type of
switching
element
Material No. Material No.
206 - 274 M12x1.5 125 °C 12-50-125 TCR.10498440 TCR.03658012
366 - 650 M18x1.5
85 °C 18-60-085 TCR.10672470
TCR.03658018
90 °C 18-60-090 TCR.10642650
110 °C 18-60-110 TCR.10642630
125 °C 18-60-125 TCR.10499540
140 °C 18-60-140 TCR.10499550
160 °C 18-60-160 TCR.10499560
180 °C 18-60-180 TCR.10499570
750 - 1330 M24x1.5
85 °C 24-75-085 TCR.11973940
TCR.03658024
125 °C 24-75-125 TCR.10488230
140 °C 24-75-140 TCR.10653470
160 °C 24-75-160 TCR.10633550
180 °C 24-75-180 TCR.10488220
Table 14
